Key Features
4MP (2560 × 1440) Resolution
4.0mm Focal Length
20 Meter Night Vision IR Distance
Built In Mic
1 Year Brand Warranty
Original price was: 2,800.00৳ .2,600.00৳ Current price is: 2,600.00৳ .
Specification:
Basic Info |
|
|---|---|
| Brand |
Uniview
|
| Model |
UAC-T114-F28G-W
|
Design |
|
|---|---|
| Product Type |
CC Camera
|
| Form Factor |
Dome
|
| Camera Type |
Fixed
|
| Usage |
Indoor/Outdoor
|
| Casing |
Plastic
|
| Body Color |
White
|
| Mount |
Wall / Ceiling / Surface/Optional Backbox
|
Camera |
|
|---|---|
| Image Sensor |
1/3” CMOS Sensor
|
| Mega Pixel |
4MP
|
| Camera Resolution |
4MP: 2560(H) × 1440(V)
1080P: 1920(H)×1080(V)
|
| Day & Night |
IR Cut Filter
|
| Night Vision |
Yes
|
| Night Vision Mode |
24/7 Color Images
|
| Slow Shutter |
PAL: 1/25s-1/50000s, NTSC: 1/30s–1/50000s
|
Lens |
|
|---|---|
| Lens Type |
Fixed-focal
|
| Mount Type |
M12
|
| Focal Length |
4.0mm
|
| Field of View |
H: 100.9° V: 56.5° D: 121.8°
|
Illuminator |
|
|---|---|
| Illuminator |
Two IR illuminators
|
| IR Range |
20 Meter
|
| Minimum Illumination |
0.005 lux (F1.6, AGC ON)
0 lux (IR on)
|
| Lifetime |
≥60,000 Hours
|
Image |
|
|---|---|
| Wide Dynamic Range (WDR) |
DWDR
|
| Image Enhancement |
BLC
|
| White Balance |
Two Modes: Auto (default), Manual
|
Video |
|
|---|---|
| Frame Rate |
TVI/AHD/CVI: 4MP@25fps (default), 4MP@30fps,1080P@25fps, 1080P@30fps, CVBS: PAL, NTSC
|
Audio |
|
|---|---|
| Built-in Mic |
Yes
|
| Camera audio |
TVI: 4MP@25fps, 4MP@30fps,1080P@25fps, 1080P@30fps
CVI: 4MP@25fps, 4MP@30fps
|
Power |
|
|---|---|
| Power Supply |
DC 12V (±25%)
|
| Power Consumption |
Max 3.5W
|
Security |
|
|---|---|
| Ingress Protection |
IP67
|
| Surge Protection |
4KV
|
Certification |
|
|---|---|
| CE |
CE, FCC, UL
|
Additional Info |
|
|---|---|
| Made in |
China
|
Physical Description |
|
|---|---|
| Dimensions |
Φ118 x 96mm
|
| Weight |
205 mg
|
Warranty |
|
|---|---|
| Warranty |
1 Year
|
| Warranty Details |
1 Year Brand Warranty
|
| Warranty Policy |
No Warranty for Physical & Burn Damage
|
Description:
Description
Designed for demanding security environments, the UAC-T122-AF28MG-W combines Uniview’s ColorHunter technology with a rugged metal chassis for consistent performance day and night. With its bright white-light illumination and built-in audio, it provides full-colour evidence in total darkness. Its high reliability makes it suitable for factories, warehouses, gates and outdoor perimeters requiring clear audio-video security. |
